HON-BIOEM-1000FV Vein and Fingerprint Access Control

Product Details:

Usage/Application	EASYACCE3.5
User Capacity	1000
Battery Backup	No
Connectivity Type	Wired
Display Type	LCD
Transaction Storage	100000
Interfaces	TCP/IP
Screen Size	2.8 inch
Power Supply	12 Volt 4 Amp

Multi-biometric Finger Vein and FingerprintRecognition Technology Based AccessControl Reader

HON-BIOEM-1000FV/HON-BIOMI-1000FV is a multi-biometric reader capable of capturing and processing finger vein and fingerprint biometric data at the same time. Ergonomic, intuitive and highly secured, HON-BIOEM-1000FV/HON-BIOMI-1000FV leads us to a new era of enhancing security with biometrics. Its infra-red rays illuminates the vein pattern which is then converted into a biometric template. Both the vein and fingerprint templates are then stored in the database for subsequent matching.

S P E C I F I C A T I O N

CPU 1.2GMHzCOMMUNICATION TCP/IPVEIN CAPACITY 1,000FINGERPRINT CAPACITY 1,000AUTHENTICATION Finger vein, fingerprint and card (optional)AUXILIARY TERMINAL 1 Aux. inputWIEGAND Wiegand outDISPLAY 2.8-inch capacitive screenOPERATING VOLTAGE DC 12V 3AOPERATING TEMPERATURE -10°C ~ 45°CDIMENSIONS 232mm×91mm×117mm(length×width×thickness)Enrollment Software EasyAccess3.5

Additional Information:

Item Code: HON-BIOEM-1000FV
Production Capacity: 300
Delivery Time: 6 Days
Packaging Details: 1. HON-BIOEM-1000FV Access Machine 2. Installation Manual
